Intesis M-Bus – BACnet/IP server INBACMEB0500100 - 50 devices

M-Bus – BACnet/IP server Gateway INBACMEB0500100

Integrate any M-Bus device with BACnet. The purpose of this integration is to make M-Bus devices, their registers and resources accessible from a BACnet-based operating system or device as if it were part of the native BACnet system and vice versa.

The gateway configuration is performed using the Intesis MAPS software . This allows you to define your own settings for the device. It can also download all available project templates or import created/exported project templates to your computer.

Characteristics

• UL certified.
• BTL certified.
• Scan: Automatic identification of M-Bus devices (meter detection) and detection of registers.
• Built-in M-Bus level converter.
• Supports the physical layer of BACnet/IP.
• BACnet advanced features available (trend logs, calendars, etc.)
• Configuration via IP port (console).
• Easy integration with Intesis MAPS.
• Automatic updates for both Intesis MAPS and the interface firmware.
